Toyota Techstream Smart Key Programming



This article show a guide on how to perform all keys lost programming for Toyota via Toyota TIS Techstream. The Immobilizer and Smart Key Reset is a feature that allows the registration of new keys when all master keys are lost. Once the system is reset, all previously registered keys will be erased. I bought a cheap OBD-2 to USB dongle and downloaded Techstream onto a laptop and was able to program my two 2008 Tundra key fobs. It was pretty easy. You don't need an original key. You just put the new keys into the ignition and then it programs the chips or pulls the key from the chip onto the ECU so that it knows to recognize it. If you want to save about 75% on the price of a Toyota transponder chip key, you can buy the key and program it yourself. A Toyota dealership will charge you 3 times what it will cost you to program a key yourself. Most people don't realize that you can't just make copies of keys anymore.

This article show a guide on how to perform all keys lost programming for Toyota via Toyota TIS Techstream.

The Immobilizer and Smart Key Reset is a feature that allows the registration of new keys when all master keys are lost. Once the system is reset, all previously registered keys will be erased . Follow the procedures in this bulletin to reset a vehicle Immobilizer or Smart Key system.

NOTE:

There are new security provisions required to obtain a Reset Pass-Code. It is critical that the instructions for this new process are reviewed BEFORE attempting to get a Pass-Code in the new system.

And the guide use the TIS Techstream Software version 9.10.037 or later is required.

Latest Toyota TIS Techstream V13.10.019 software, free download

Some Related Contents:

How to use Toyota TIS Techstream

Toyota TIS Techstream v12.20.024 Installation Guide

Toyota TIS Techstream Program A New Key For Lexus ES330

Program New Key for Toyota Tundra by TIS Techstream

Toyota Vehicle Models Compatible(1998-2015):

4Runner, Avalon,Avalon HV, Camry,Camry HV, Corolla,Corolla BR-Prod, FJCruiser, Highlander,Highlander HV, LandCruiser, MR2 Spyder,Matrix, Prius, PriusC, Prius PHV, PriusV, RAV4, RAV4 EV,Sequoia, Sienna,Solara, Tacoma,Tundra, Venza, Yaris

Service Bulletin Overview

1.Review the vehicle application chart in the Technical Information System (TIS) to verify the vehicle is capable of being reset.

Toyota

Refer to the Toyota I Scion Vehicle Support chart located on TIS, under Diagnostics -Immobilizer Reset – Reference Documents.

2.Review the new security authorization process and chose the option that best supports your dealer situation.

3.Follow the Techstream and TIS screenshots to obtain the Pass-Code needed to open registration for Immobilizer and Smart Key programming.

NOTE:

Some early ECM based Immobilizers cannot be reset using Techstream. For these vehicles, do the following: Identify the vehicle using the Toyota I Scion Vehicle Support noted above. Refer to the most recent PANT bulletin for instructions.

Section 1: Security Authorization for the Reset Pass-Code

An improved security measure has been implemented in TIS that requires a secondary approval by dealer management each time an Immobilizer or Smart Key Reset request is submitted. Please review the following flow chart and become familiar with the options outlined prior to attempting a vehicle reset.

Figure 1. Immobilizer Reset Process

Key Points:

The Reset request can be submitted from the Techstream in the vehicle, or on TIS before the vehicle is available.A single management approval can be used multiple times for the same VIN as needed until the vehicle repair is completed.Each Reset attempt for the same VIN will generate a new Seed Number and a unique Pass-Code.The request and approval hand-off between technician and management is done on the TIS home page inbox accessed at each individual’s location (Techstream, office, etc.).

Main Steps:

1.Obtain Authorization

A.Technician Reset Approval Request

B.Manager Access TIS In-Box Message and Approve

2.Perform Reset with Techstream

A.Access Approval In-Box Message

B.Perform Reset at Vehicle

Variations:

1.Pre-approval before vehicle is accessed (as per above Main Steps)

2.Request and receive approval from Techstream after entering the reset utility

3.Repeated reset attempts with Techstream by accessing the single approval file

Approving Managers:

Once the Pass-Code Request form has been completed an approval request will be sent to all approving managers. Dealership personnel with the following job titles in “Staffmaster” are granted Pass-Code approval capability.

Dealer Principal, General Manager, Service Manager, Service Director, Service/Parts Director, Parts Manager, Parts Director, Customer Relations Manager, Customer Satisfaction Manager, Shop Foreman,Diagnostic Specialist, Team Leader Each dealer must have at least 2 enrolled managers in order to accessany Pass-Codes.

NOTE:

Once a Reset is completed, it may be necessary to enter an “Immobilizer Key Registration” or a “Smart Key Code Registration” utility to program the new keys. Early Immobilizer systems may be ready to accept keys immediately after the Reset if the security light flashes a 2-digit code (such as 21 or 22). Refer to the applicable Repair Manual for details.

Please review the Techstream and TIS screenshots in this bulletin to become familiar with the new management authorization process flow.

Section 2: Reset Approval Request (TIS Pre-Approval)

1.Open TIS and enter the Diagnostics and Immobilizer Reset tabs. Login using your password.

Figure 2.

2.Enter the information requested , check all 4 boxes below Positive Identification Policy, then click Next.

Figure 3.

3.A minimum of two managers are required to be selected. Once two or more managers are selected, click Submit to continue. Each request is required to be approved by one manager.Once manager approval is received , continue to Section 5, “Receipt of Pass-Code.”

Figure 4.

Section 3: Techstream Reset Utility (With Request)

1.Connect Techstream to the vehicle.

Figure 5.

2.Choose the appropriate vehicle model and year if the ignition cannot be turned on and the

information does not automatically populate.

Figure 6.

3.Choose the Immobilizer or Smart Key system as needed.

Figure 7.

4.Choose the Immobilizer or Smart Code Reset utility.

Figure 8.

5.Enter the VIN if prompted.

Figure 9.

6.Techstream will generate a Seed Number. Click Get Pass-Code.

Figure 10.

7.Click Send to connect to TIS.

Figure 11 .

NOTE:

If there is already a management approval file for this VIN, DO NOT follow the next 3 steps to resubmit a request. Open the approval file in your TIS inbox and enter the most recent Seed Number to get the Pass-Code (as outlined in Section 5, “Receipt of Pass-Code’). Then go to Section 6, ” Techstream Reset Utility (Reset Initiated).”For repeated Reset attempts after the approval is completed, follow Sect ion 3, ” Techstream Reset Utility (With Request),” and Section 6, ” Techstream Reset Utility (Reset Initiated),” using the same management approval file.

8.When the TIS window opens, enter your password to login.

Smart

Figure 12.

9.Fill in the required information and select Next.

Figure 13.

10.A minimum of two managers are required to be selected. Once two or more managers are selected , click Submit to continue. Each request is required to be approved by one manager.Once manager approval is received , continue to Section 5, “Receipt of Pass-Code.”

Figure 14.

Section 4: Manager Approval (TIS)

1.Once the request has been submitted, one of the authorized dealer managers will locate the technician ‘s request in their TIS home page inbox.The manager clicks the title to open the Request.

Figure 15.

2.The manager checks the 3 boxes under Request Approval Policy, then selects Approve to send the approval to the technician.

Figure 16.

Section 5: Receipt of Pass-Code (TIS)

1.Once approved by management, the technician opens his TIS inbox and locates the Reset request. The technician clicks the title to open the Approval.

Figure 17

NOTE:

It is recommended to retrieve the Pass-Code from the Techstream connected to the vehicle as the Seed Number and Pass-Code work together.Once approved by management, multiple resets can be performed for a single VIN.Each attempt will create a new Seed Number and resultant Pass-Code.

2.Once opened, the technician clicks the Immobilizer Reset link to continue.

Figure 18.

3.At this point, it is necessary for the technician to re-enter their password to login again.

Figure 19.

4.The technician must enter the Techstream software version and paste in the Seed Number from Techstream, then click Next.

Figure 20.

5.The Pass-Code will then be provided as shown. Continue to Section 6, “Techstream Reset Utility (Reset Initiated),” for instructions on entering the Pass-Code to initiate the Reset.

Figure 21 .

Section 6: Techstream Reset Utility (Reset Initiated)

The Reset can be initiated once the management approval reply is available in the TIS home page

inbox. With this approval file, multiple Seed Numbers can be used for as many attempts as needed to repair the vehicle.

NOTE

If you have received the file from management in your TIS in box that shows the approval status for the given VIN, do NOT resubmit for another approval for this vehicle. It will not be necessary.Continue to open the approval file and enter a new Seed Number to get the unique Pass-Code for each attempt.

1.After retrieving the Pass-Code from the manager approval process in Section 4 (“Manager Approval’) and Section 5 (“Receipt of Pass-Code”), enter the Pass-Code in Techstream and click Next.

Figure 22

2.Click Yes to start the process.

Figure 23.

3.Once completed , it may be necessary to enter either the Immobilizer Key Registration or Smart Code Registration utility to program keys.

Figure 25.

NOTE:

Some early Immobilizer systems go directly into programming mode. This can be confirmed by the security light blinking a 2-digit code. Refer to the applicable Repair Manual for details.

How useful was this post?

Click on a star to rate it!

Average rating / 5. Vote count:

This Post: Toyota TIS Techstream All Keys Programming for Toyota From ChinaOBD2 Official Blog
Please keep this link if you copy the post!


DIY Programming technique for Toyota, Lexus, and Scion smart key & remote fob.

A few years ago I bought my used 2008 Toyota Highlander Limited and it came with just one “Smart Key” to start the engine. Initially, I wanted to get a second key for a backup, but few hundred dollars price tag from the dealer made me hold off on that idea. A few months later someone commented on my Youtube channel that it is possible to program any Toyota, Scion or Lexus smart key using a special cable and software, so I started my online search. After some struggling and few failed attempts, I finally figured out the way to do it. It still cost me quite a lot of $$$, but nevertheless, I still saved about $100 compared to the dealer’s price.

Disclosures

The following smart key programming instructions are not guaranteed to work. Performing this procedure can potentially damage your vehicle, void your vehicle warranty, and cause expensive repair costs. Do it at your own risk. You can also visit our full Legal Disclosure page.

Here is what you will need:

    1. Windows-based PC laptop computer
    2. Diagnostic software and cable (USB to OBD2)
    3. New Toyota, Lexus or Scion Smart Key fob with unlocked smart chip transmitter
      (these are eBay affiliated links)
    4. TechStream “Professional” subscription (https://techinfo.snapon.com/TIS/Register.aspx).

Step 1

In order to program Toyota, Lexus or Scion smart key, you will need to get the diagnostic software and USB to OBD2 cable. You will need to install the software and the driver on your Windows XP, 7, 8 or 10 computer or tablet. Installation instructions are usually provided with the purchase of the cable.

Step 2

Next, you’ll need to purchase a new original OEM unlocked Smart Key fob. You can also buy a used Smart Key if you want to save money, just make sure you are buying unlocked one. Otherwise, you will have to find someone to unlock it for you, like your local Locksmith or hardware store (though very often they will refuse to do that and offer to buy their keys instead). Search for smart keys compatible with specific make, year, and model of your Toyota, Lexus or Scion.

Step 3

Install cable drivers and diagnostic software on Windows PC based computer. Installation instructions are usually included with the purchase of software and the cable.

Step 4

Programming Instructions:

  • Connect your computer to OBD2 port under the dashboard of your car using the included cable
  • Launch TechStream software and click on “Connect to Vehicle”
  • Select your car make, model, year, engine
  • Choose “With Smart Key” option
  • *If your car doesn’t have smart key fob, choose “Without SmartKey”. Programming instructions will be different.
  • Select “Smart Key” system
  • Click on “Utility” button
  • Select “Smart Code Registration”
  • Press the Start button in your car once to turn the engine/power ON
  • Remove any devices that may cause electromagnetic interference, such as cell phones
  • Be aware that you will need to perform each step within the specified amount of time
  • Only carry one smart key into the vehicle at a time
  • Check four checkboxes and click “Next”
  • Notice the number of available spaces for a new key. If the number of available spaces is 0, then you need to go back to “Smart Code Reset” utility firs
  • Place already registered smart key into the car, and remove the new unregistered smart key from the car, and click “Next”
    (I rolled down the window and placed the unregistered key on the roof of my car, and it worked just fine)
  • Press “Pre-Start Check” button and review registration process

New Smart Key Registration Process

  • Press “Start” button to start registering process
  • Within 30 seconds touch engine start switch/button with your registered smart key. You will hear one beep
  • Within 30 seconds remove the registered key from the vehicle, place the new unregistered key into the vehicle, and touch the engine start switch/button with the unregistered smart key. You will hear one beep
  • Place the key on the passenger seat. New smart key registration is complete!
  • Test new smart key to verify it is working
  • You can press “Next” to register more keys, or “Exit” to finish.

You can also watch me using this method to program a spare smart key for my 2008 Toyota Highlander Hybrid Limited:

Please Share Your Experience!

Thank you for checking out our website. We hope these programming instructions were helpful and saved you a lot of money. If so, please please give back to DIY-time community and share your experience in the comments section below (no registration required). Tell us if you were able to register your smart keys; what is the make, year and model of your car; what problems you ran into and how you fixed them, etc. We will update the content of this page, compatibility list, and FAQ with your input.

Compatibility

Techstream Download Key

These instructions work for various Toyota, Lexus, and Scion equipped with a smart key. The following Toyota models: 4Runner, Avalon, Camry, Celica, C-HR, Corolla, Echo, FJ Cruiser, Highlander, Land Cruiser. Matrix, MR2, Paseo, Prius, Rav4, Sequoia, Sienna, Solara, Supra, Tacoma, Tundra, Venza, or Yaris. Lexus: CT200h, ES250, ES300, ES330, ES350, GS F, GS200t, GS300, GS350, GS400, GS430, GS450h, GS460, GX460, GX470, HS250h, IS F, IS200t, IS250, IS250c, IS300, IS350, IS350c, LFA, LS400, LS430, LS460, LS600h, LX450, LX470, LX570, NX200t, NX300h, RC F, RC200t, RC300, RC350, RX300, RX330, RX350, RX400h, RX450h, SC300, SC400, or SC430. The following Scion models: FR-S, iA, iM, iQ, iQ EV, tC, xA, xB, or xD.

Programming Toyota Ignition Key

Mercedes smart key programming

Troubleshooting Tips.

Toyota Transponder Key Programming Instructions

If you weren’t able to program your Lexus Smart Key, visit my Troubleshooting Tips page here, where I’ll try to answer the most frequently asked questions. I will try to update this list if I receive new questions or information. If you don’t find your answer, feel free to ask it in the comments area below. I or other readers may know about your problem to help you with your question. Likewise, if you see others asking questions, feel free to chime in if you feel like you know the right answer. Let’s help each other here by sharing our knowledge and experience.
